Overview

UMI Performance Competition Front End Kits

Tremendous front grip and a host of features can be yours with UMI Performance Competition front-end kits. The included A-arm kit enables 10 degrees caster while maintaining standard track width and wheelbase. Lower A-arms are assembled with tall lower ball joints to optimize roll center, camber gain, and center of gravity. Lower A-arms feature Delrin bushings for smooth travel and bind-free performance.

The new lower A-arm works in conjunction with the included adjustable upper arm—which features minimum shim adjustability, Pro Forged ball joints, and super-smooth PTFE lined rod ends. The front sway bar attaches using UMI’s swivel-style end link design and double shear mounting system. The included Viking Crusader coilover shocks mount to the lower A-arm in double shear quick-change brackets. The lower shock mount is removable to allow spring and shock changes at the track.

UMI’s kit features Viking Crusader shocks with AT pro-touring valving (high rebound tie-down for road race and autocross) and a true 2.5 in. racing coilover. The upper stud mount fits in the factory location, while the lower is optimized to fit UMI’s 3057-1 coilover lower A-arm. Some grinding is required for installation in the upper frame spring bucket. Other spring rates and valve codes are available. The Competition kits have been battle-tested on the iconic UMI Green Machine. Kits are available in red or black powdercoat; and are 100 percent designed, manufactured, and raced with pride in the USA.
